• DVB-T2
• HDMI
• USB Media
• Dolby Audio

Hardware

Processor / Cores MSD3666

Dual Tuner No

Colour (Front bezel, rear, stand) Black / Black / Black

Speakers mounted in enclosure No

Mains power switch No

Swivel base No

Compact packaging Yes

Hotel Lock

Protected Hotel lock submenu Fixed code

Clone function for programs, sound and image settings No

Sub-menu lock, including tuning lock Yes

Keyboard lock No

Maximum volume lock Yes

Power on volume Yes

Power on, apply default sound/image settings Yes

Power on source selection Yes

Power on RF channel selection Yes

Power on mode (On / Standby / Last) Yes / Yes / Yes

Inputs access (Enable / Disable) Yes

USB Media Player

Personal Video Recorder Yes

Time Shift Yes

DTV Recording EPG scheduling, Start from Standby

DivX decoder No

MPEG4 H.264 / H.265 Decoder No / No

DMP – Digital media player content Music, Photos, Video

DMP Auto-play No

DMP for UHD content via USB No

DMP File allocation table FAT, FAT32, NTFS

PVR File allocation table FAT, FAT32, NTFS

Image processing

Backlight control No

Light sensing No

Dynamic backlight control No

Local dimming / controllable zones No

Zoom function settings 16:9, 4:3, Auto, Zoom 1, Zoom 2

1:1 Pixel mapping No

HDR – High Dynamic Range for luminance DMP, HDMI, Netflix

HDR system No

HLG No

HEVC (H.265) decoder No

Dual image No

MEMC No

Analogue TV Reception

Colour-Sound systems in VHF band PAL B

Colour-Sound systems in UHF band PAL B

Stereo sound decoder (Analogue) NICAM

Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX (Analogue) No

Subtitles (Analogue) Yes

Digital TV Reception

Television system DVB-T, DVB-T2

Video decoder (MPEG2 / MPEG 4) MPEG2, MPEG4

AC3 Surround sound decoder Yes

AS 4599.1 Compliance No

AS 4933.1 Compliance No

LCN – Logical channel number & DTV Service name support No

Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX No

Subtitles Yes

RF Signal strength indicator No

RF Signal quality indicator No

RF Bit error rate indicator No

EPG - Electronic Programming Guide, 7 days for all services No

Audio description (vision impairment aid) No

Parental rating lock No

Smart TV

Ethernet RJ45 port 0

Wi-Fi protocols IEEE 802.11 [b, g, n, ac, ad, ..] No

Wi-Fi bands No GHz

Network Streaming (DLNA) No

Bluetooth No

Anyview Cast No

UHD (4k) streaming No

Installed Apps No

Freeview Plus – HbbTV 2.0 No

Web browser No

Eco & Power Supply

Power Consumption (Stand-by) < 0.5 W

Voltage 100 – 240V

Frequency 50 – 60Hz

Functions

Smartphone app No

Safety and Regulation

CB Yes

EMC Yes

HDMI Yes (Hisense internal test)

RoHS No

Accessories

Remote Control Yes

Remote Batteries AAA x 2

User Manual Yes

Stand area 671 × 160mm

Wall mount dimensions 100 x 200mm

Wall mount, screw thread M6

VESA compliance Yes

Detachable power cord No

Power cord length 155 cm

Remote controller (Technology / Part number) IR / EN2T30H

Warranty In separate sheet

Weight & Dimensions

Carton box dimensions (W x H x D) 811 x 129 x 515 mm

Gross Weight (Kg) 5,5 kg

Dimensions with stand (W x H x D) 717 x 469 x 160 mm

Dimensions without stand (W x H x D) 717 x 427 x 86 mm

Net weight (with stand / without stand) 3.6 / 3.7 kg

Connectivity

HDMI inputs 2

HDMI1 ARC, HDMI type 1.4 with HDCP version 1.4

HDMI2 HDMI type 1.4 with HDCP version 1.4

Radio frequency input 1

AV Input 1

AV Output 0

USB (2.0) 2

USB (3.0) 0

S/PDIF Output 1

Earphone jack 1

Ethernet RJ45 port 0

Features

On / Off timer Yes

Power off if no signal Yes

Sleep timer Yes

Program lock Yes

OSD transparency control No

User Interface (UI) Linux

Software version OSD indication Yes

Legal requirements Acceptance of Terms, Disclaimer

Favourite channel list Yes

Electronic point of sales (E-POS) No

OTA - Over the air software updates No

Voice command No

Screen mirroring No

Smartphone app No

Replaceable demo video for Store mode No

Remote control via serial port No

Internet

Installed Apps No

Web browser No

Anyview Cast No

Sound

Audio Power Output (p/ch) 6 W

Number of speakers (Tweeter / Midrange / Woofer) 0 / 1 / 0

Automatic volume level (AVL) Yes

Audio equalizer Yes

Audio enhancement – Type [SRS, BBE, SAP, DBX-TV...] No

Lip-sync adjustment No

Dolby Digital Yes

Technical Details

Resolution (DPI) 1366 x 768

HDMI-CEC Support Yes

MHL Support No

Network Streaming (DLNA) No

Wide Colour Gamut No

MEMC No

HLG No

Basic Information

Resolution (DPI) 1366 x 768

Display Technology LCD / LED lit

RoHS No

User Interface (UI) Linux

Active display area dimension 697,685 x 392,256 mm

Screen size (rounded to nearest integer) 32 ", 80 cm

Backlight source LED Matrix

Display Colour depth 8bit

Image refresh frequency 60Hz

Smooth motion rate 120

Maximum brightness of white 300cd / m2

Native contrast ratio 3000 : 1

Viewing Angle (Horiz / Vert) 178 / 178 Degrees

Quantum dot No

Wide Colour Gamut No

UHD Premium No

Response Time 6,5 ms

36 Months
