Condenser Outdoor coil

Number of rows COC

2

Tube pitch(a)x row pitch(b) COC

21×18.19

Fin spacing COC

1.4

Fin type (code) COC

hydrophilic aluminium

Tube outside dia.and type COC

Ф7 innergroove tube

Coil length x height x width COC

(841+813) x 546 x 18.19

Number of circuits (Inlet and Outlet) COC

In:4, Out:4

Evaporator Indoor coil

Number of rows

2

Tube pitch(a)x row pitch(b)

21×13.6

Fin spacing

1.4

Fin type (code) EIC

hydrophilic aluminium

Tube outside dia. and type

Ф7 innergroove tube

Coil length x height x width

705 x 378 x 27.2

Number of circuits (Inlet Outlet)

In:4, Out:4

Dimensions

Net Dimensions – WxHxD (mm) Indoor Unit

960×315×235

Net Dimensions – WxHxD (mm) Outdoor Unit

810x585x280

Net Weight (Kg) Indoor Unit

12.5

Net Weight (Kg) Outdoor Unit

40.5

Packing Dimensions WxHxD (mm) Indoor Unit

1022×380×302

Packing Dimensions WxHxD (mm) Outdoor Unit

940x630x385

Gross Weight (Kg) Indoor Unit

15.5

Gross Weight (Kg) Outdoor Unit

45

Loading Capacity (20’/40’/40’HC ) with pipe

86/180/201

Loading Capacity (20’/40’/40’HC ) without pipe

86/180/201

Approvals

CB

Filter information

HEPA Filter

Optional

Features

Display on Front Panel

LED

LCD Wireless Remote Controller

Yes

Removable and washable Panel

Yes

Active Charcoal Filter

Optional

Electrostatic Filter

Optional

LTC Filter

Optional

Catechin filter

Optional

Negative ion filter

Optional

Photic Catalyst filter

Optional

Vitamin-C filter

Optional

Dimmer

Yes

24 Hours Timer

Yes

Timer ON/OFF

Yes

5 Speed and Auto Indoor Fan Control

Yes only 3 speed

Silent Mode

Yes

Horizontal Auto Swing Louver

Yes

Manual Adjustable Vertical Louver

Yes

Top Down Horizontal louvers features for cooling mode

Yes

Sleep function

Yes

Smart sense function

Yes

Super function

Yes

Compressor Indicator

Yes

Auto Restart

Yes

Auto Defrost

Yes

Dehumidification function

Yes

Cold air protection

Yes

Annual energy consumption

860

High density Filter

Yes

Connecting Pipe Diameter

Liquid Pipe (inch)

3/8

Gas Pipe (inch)

5/8

Maximum connection pipe length

15

Maximum height difference

5

System

Compressor type

Rotary

Compressor Model No.

ASH201RV-C8DQ

Compressor MFG

Highly

Expansion Device

Flow restrictor

Evaporator

Copper tube and Aluminum Fin

Condenser

Copper tube and Aluminum Fin

Power Supply

Voltage

220-240V

Frequency

50Hz

Phase

1P

Rated Current Cooling (A)

7.7

Rated Current Heating (A)

6.9

LRA

43

Ratings

Cooling Capacity

5384

Heating Capacity

5340

Power Input-Cooling

1720

Power Input-Heating

1540

Moisture Removal

1.8

Air Circulation

950

EER

3.13

COP

3.47

Energy Class for Argentina (Cooling)

B

Energy Class for Argentina (Heating)

A+

Refrigerant

R410A

Refrigerant volumn

1460

Unit Noise Level

INDOOR: (HIGH) = 43, (LOW) = 38 / OUTDOOR: 54

Specs

Type Of AC

Heat pump
